Specifications
LCD Specs
Diagonal Size
35“
Panel Type
IPS LCD Panel
Active Area
877.824(H) ×45.72(V)mm
Resolution
3840×200(RGB) 111PPI
Brightness
500cd/㎡ (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Display Color
1.07B , 72% NTSC
Backlight
WLED
Viewing Angles
89/89/89/89 (Typ.)(CR≥10)
Response Time
8 (Typ.)(G to G) ms
Frequency
Frequency
Lifespan
≥50000 hours
Motherboard Specs
CPU
T972 Quad core ARM Cortex-A55
RAM
2G DDR4
ROM
16G EMMC
Memory Extension
TF card expansion supports up to 128GB
Operation System
Android & Linux System Optional
Intetnet
Support 2.4G WIFI connection
RTC Real Time Cock
Support timing on / off function
Interfaces
TF card slot
1
Micro-USB(OTG)
1
Type-c(DC 12v)
1
USB
1
Display Specs
Operating Voltage
100-240V (50/60Hz)
Power Consumption
≤30W
Outer Dimensions
891.6*60.4*23.1mm
Installation
Mounting bracket
Materials
Sheet Metal materials
N.W
≤1.5KG
Housing Treatment
Black metal paint
Environment
Storage Environment
Temperature：-20℃～60℃ Humidity：5%～95% Atmospheric Pressure：86kPa～104kPa
Working Environment
Temperature：-10℃～50℃ Humidity：10%～85% Atmospheric Pressure：86KPa～104KPa
Packing list
Display
1pc
OTG/Cable
1pc (OTG cable，micro USB to USB 2.0)
Adapeter
1pc (12V-2A)
Bracket
1pc
Certifications
CE
Issued by SGS
RoHS
Issued by SGS
REACH
Issued by SGS
FCC ID
Issued by SGS
